| 產品型號 | 通道數 | 頻率範圍 | 連接器類型 |
|---|---|---|---|
| ZNA26 | 2/4 | 10 MHz - 26.5 GHz | 3.5 mm(m) |
| ZNA43 | 2/4 | 10 MHz - 43.5 GHz | 2.4 / 2.92 mm(m) |
| ZNA50 | 2/4 | 10 MHz - 50 GHz | 2.4 mm(m) |
| ZNA67 | 2/4 | 10 MHz - 67 GHz | 1.85 mm(m) |
| ZNA67EXT | 2/4 | 10 MHz - 110 GHz | 1.0 mm(m) |
軟體選項
| 軟體型號 | 軟體類型 | 軟體說明 |
|---|---|---|
| R&S ZNA-K1 | General | Spectrum analyzer mode |
| R&S ZNA-K2 | General | Time domain analysis (TDR) |
| R&S ZNA-K4 | General | Scalar mixer measurements, arbitrary frequency-converting measurements |
| R&S ZNA-K5 | General | Vector mixer measurements |
| R&S ZNA-K6 | General | Phase coherent source control |
| R&S ZNA-K7 | General | Measurements on pulsed signals |
| R&S ZNA-K8 | General | mmWave converter support |
| R&S ZNA-K9 | General | Group delay measurements on frequency converters without LO access |
| R&S ZNA-K17 | General | Increased IF bandwidth 30 MHz |
| R&S ZNA-K19 | General | 1 mHz frequency resolution |
| R&S ZNA-K20 | General | Extended time domain analysis (including eye diagram) |
| R&S ZNA-K30 | General | Noise figure measurement |
| R&S ZNA-K50/K50P | General | Uncertainty analysis/Uncertainty analysis, pre-installed |
| R&S ZNA-K51 | General | Security write protection |
| R&S ZNA-K61 | General | True differential mode |
| R&S ZNA-K210 | General | EaZy deembedding |
| R&S ZNA-K220 | General | In-situ deembedding |
| R&S ZNA-K230 | General | Smart fixture deembedding |
| R&S ZNA-K231 | General | Delta-L PCB characterization |
